SKU: AT101-868M
The Milesight AT101 is a rugged, LoRaWAN®-based outdoor asset tracker designed for long-term, high-precision location monitoring.
Details Additional Info Data Sheet Manual
The Milesight AT101 is an exceptional outdoor tracker that combines GNSS and Wi-Fi AP MAC Address Scanning technologies to deliver highly accurate positioning data. It is equipped with tilt and temperature sensors, enabling extensive data collection and versatile applications in various scenarios.
The AT101 allows asset/property owners to ensure awareness of critical assets comes first by utilising GNSS and cooperating with Wi-Fi location.
Under motion mode, users can turn on “Reporting Interval during Motion” to obtain the trajectory of vehicles for anti-theft positioning or progress management.
Geofencing is focused on the virtual perimeter you build around a specific geographic location. Users can receive alerts when assets leave/return to defined zones.
Ideal for a wide range of applications, including:
We can supply a third-party online wireless sensor monitoring and notification system to view data and set alerts via SMS text and email. Ask us about our zero-touch provisioning service, this sensor can be supplied pre-configured and ready to go.
| Protocol | LoRaWAN ® |
| Frequency | EU868 (Other frequencies available on request) |
| Tx Power | 16 dBm (868 MHz)/20 dBm (915 MHz)/19 dBm (470 MHz) |
| Positioning | GNSS (GPS/GLONASS/Galileo/Beidou), Wi-Fi Scanning, Bluetooth |
| Dimensions | 110 × 70 × 30 mm (4.33 × 2.76 × 1.18 in) |
| Weight | 202g (Batteries are Included) |
| Operating Temperature Range | -30°C ~ +70°C |
| Ingress Protection | IP67 |
| Enclosure Material | Polycarbonate (Flame Retardant & Anti-UV) |
| Input Power | 4 × 2700 mAh ER14505 Li-SOCl2 Replaceable Batteries |
| Battery Life | Twice Daily Location Updates - 15 + Years Tenth Daily Location Updates - 8 + Years Hourly location updates – 4 + Years |
Certifications
