Milesight GS601 Vape Detector

SKU: GS601-868M

The Milesight GS601 is a vape detector sensor, designed to detect vapours from e-cigarettes, cigarettes and cannabis.

Details Additional Info Data Sheet Manual

Quantity:

- +

£154.58 (RRP) +VAT


Product Description

The Milesight GS601 is a LoRaWAN® vape detector designed to identify vaping and smoking events. Equipped with a suite of powerful embedded sensors, GS601 simultaneously measures temperature, humidity, TVOC, and PM parameters.

When environmental changes reach the preset thresholds, the detector activates both the LED light alarm and buzzer sound alarm. In addition to local alerts, the GS601 can also remotely report the air quality status and alarm messages via LoRaWAN® technology. By integrating with a LoRaWAN ® gateway and your chosen dashboard, users can visually monitor all sensor data and manage the device remotely.

GS601 seamlessly blends into various installation environments, making it ideal in restrooms, changing rooms, classrooms, stairwells, apartments and other locations.

The Milesight GS601 is suitable for a wide range of applications, including:

  • Education Institutions
  • Commercial Buildings & Offices
  • Residential Areas
  • Public Facilities
  • Smart Building & Management

Features

  •  Detects e-cigarettes, marijuana, and environmental factors
  • Integrated with multiple sensors to detect vape, smoke, TVOC, temperature, humidity, and PM parameters
  • Equipped with a buzzer and indicator to signal when the device is powered, faulty, alarmed, or in an invalid status
  • Equipped with a vibration sensor to detect acts of vandalism or tampering
  • Built-in NFC for easy configuration
  • Compatible with standard LoRaWAN® gateways and network servers

Parameters

Wireless Transmission
Protocol LoRaWAN®, Milesight D2D
Antenna Internal Antenna
Frequency RU864/IN865/EU868/US915/AU915/KR920/AS923-1&2&3&4
Tx Power 16 dBm (868 MHz) / 22 dBm (915 MHz)
Sensitivity -137 dBm @ 300 bps
Mode OTAA/ABP Class C
Vape & Smoke Detection
Detection Method Electrochemical Solid Polymer, Anti-Moisture Coating
Vape / Smoke Index 0 ~ 100 (Customisable Threshold)
TVOC Sensor
Range 1.00 ~ 5.00 (IAQ Rating)
Particulate Matter Sensor (Laser Scattering)
Parameters PM1.0, PM2.5, PM10
Range 0 ~ 1000 μg/m³
Accuracy ± 10 μg/m³ (0 ~ 100 μg/m³), ± 10% (100 ~ 1000 μg/m³)
Temperature Sensor
Range -10°C ~ +60°C
Accuracy ± 0.5°C
Resolution 0.1°C
Humidity Sensor
Range 0% ~ 95% RH
Accuracy ± 3% RH
Resolution 0.5% RH
Software & Features
Alarms LED Indicator & Buzzer (Local), LoRaWAN® Uplink (Remote)
Tamper Detection Vibration Sensor
Configuration Mobile App via NFC or Downlink
Advanced Features Anti-Water Vapour Disturbance, Buzzer Hibernate Mode, Milesight D2D Controller, FUOTA
Dimensions Ø 128 × 40 mm (Ø 5.04 × 1.57 in)
Weight 141g
Colour & Material White, PC & ABS (Flame Retardant)
Installation Ceiling Mounting
Operating Temperature -10°C ~ +60°C
Relative Humidity 0% ~ 95% (Non-condensing)
Ingress Protection IP30
Regulatory CE, FCC, RoHS
Power Supply 5V / 1A via USB Type-C Port or PoE Splitter (Optional)

Discounted Trade Pricing: Contact us for trade pricing, to place an order or to discuss your IoT projects.

All of our products are available to customers throughout Europe. For more information on shipping costs, currency conversions and lead times, please contact our technical sales team. Our technical sales team are also happy to advise customers on the best LoRaWAN® sensors to suit specific project requirements.
