SKU: WS558-868M PN: LN
The Milesight WS558 is a LoRaWAN® Smart Light Controller for monitoring and controlling lights locally or remotely. With 2 circuit types and 8 switches, it fits different rooms without the need of re-wiring,reducing the renovation costs.
Details Additional Info Data Sheet Manual
Variants:
The Milesight WS558 LoRaWAN® Smart Light Controller is more than just a device; it's a gateway to smarter, more efficient lighting management. Imagine a solution that effortlessly merges cutting-edge technology with practicality. Utilising the advanced dimming and time-based scheduling capabilities, the Milesight WS558 offers you unparalleled control over your lighting infrastructure from your smart device.
If you are looking for a simple on and off light switch to control remotely, then the WS558 switch type is your go to variant as this primarily focuses on controlling the power supply to the connected lighting fixtures. The WS558 LN type, on the other hand, offers you more advanced features such as sophisticated scheduling and more precise dimming options, allowing for more control over the lighting environment compared to basic switch models.
The Milesight WS558 LoRaWAN® Smart Light Controller provides reliable monitoring of the lighting network's performance, collecting data on usage patterns, energy consumption, and system health. These insights enable proactive maintenance and informed decision-making, helping you to become more energy efficient and reduce unnecessary spending.
Recorded data is transmitted over a LoRaWAN® network, helping to secure any privacy concerns. Based on the standard LoRaWAN® protocol, the WS558 connects to a LoRaWAN® gateway and can then be visualised by your preferred dashboard or through Milesight's IoT Cloud.
The Milesight WS558 can be used in many areas, such as:
The standout feature of the Milesight WS558 is its robust design which is purposely built to withstand varying weather conditions enabling it to excel even in harsh weather conditions.
Utilising LoRaWAN® technology, the Milesight WS558 LoRaWAN® Smart Light Controller is completely wireless. This smart device transmits recorded data to a connected LoRaWAN® gateway. The data is then sent to the smartphone app and/or your chosen third-party platform for visualisation by a LoRaWAN® network server.
| Product Name | Circuit Type | Power Consumption Measurement | Overcurrent Protection |
|---|---|---|---|
| WS558 Smart Light Controller | LN Type | ✓ | ✓ |
| WS558 Smart Light Controller Switch | Switch Type | X | X |
| Wireless Transmission | |
|---|---|
| Protocol | LoRaWAN®, Milesight D2D |
| Frequency | EU868 (Other frequencies available on request) |
| 16 dBm (868 MHz) / 22 dBm (915 MHz) / 19 dBm (470 MHz) | |
| Sensitivity | -137 dBm |
| Mode | OTAA/ABP Class C |
| Switching & Control | |
| Circuits | 8 Independently Controlled Circuits |
| Switch Control | Local Press or Remote Control |
| Configuration | NFC, USB Type-C, or Downlink |
| Advanced Features | Multicast, Remote Schedule, Overcurrent Protection, Power-Off Memory, Milesight D2D Agent |
| Electrical Measurement (LN Type Only) | |
| Measurement | Voltage (VAC), Current (mA), Power Factor (%), Power (W), Power Consumption (kWh) |
| Load Capacity (LN Type) | 5 A max per circuit, 16 A total |
| Load Capacity (Switch Type) | 10 A max per circuit, 16 A total |
| Dimensions | 145 × 90 × 40 mm (5.70 × 3.54 × 1.57 in) |
| Colour & Material | Creamy White, ABS |
| Installation | Wall Mounting, DIN Rail Mounting |
| Operating Temperature | -20°C ~ +60°C |
| Relative Humidity | ≤ 95% (Non-condensing) |
| Ingress Protection | IP30 |
| Power Supply | 100 ~ 240 VAC, 50 ~ 60 Hz |
All of our products are available to customers throughout Europe. For more information on shipping costs, trade pricing and lead times, please contact our team.
Our technical sales team are also happy to advise customers on the best LoRaWAN® Light Controller for their specific applications on an individual project basis.
